LuxLine 22" Premium Slim LED Bar (with White/Amber DRL)
LuxLine 22" Premium Slim LED Bar (with White/Amber DRL)
Couldn't load pickup availability
The LuxLine 22" Slim LED Bar (with White/Amber DRL) is a premium single-row light bar designed for both style and performance. Delivering 140W of powerful output with 9500 lumens, it features dual-function DRLs in white and amber, giving you added versatility for both day and night use.
Equipped with 14 × 12W high-intensity LED chips at a crisp 6000K color temperature, this slim bar produces a focused driving beam that cuts through the darkness with clarity. Its compact design (584 mm width) makes it the perfect fit for front grilles or roof-top mounting, blending seamlessly with modern vehicle styling.
Built tough with IP67 waterproof protection, DT connector, and E-Mark approval, the LuxLine 22" Slim LED Bar is engineered to withstand harsh off-road conditions while ensuring safe, reliable performance. Backed by a lifetime warranty, it’s a true long-term lighting upgrade for your rig.
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | LuxLine 22" Slim LED Bar (with White/Amber DRL) |
| Power Output | 140W + 10W DRL (White + Amber) |
| LED Chips | 14 × 12W High-Intensity Chips |
| Color Temperature | 6000K |
| Beam Pattern | Driving Beam |
| Lumens | 9500LM |
| Dimensions (L×H×D) | 584 × 76.3 × 70 mm |
| Operating Voltage | 9–32V DC |
| Mounting Options | Backside + Both Side Brackets |
| Installation Areas | Front grille or roof-top mounting |
| Connector | DT Connector |
| Certifications | E-Mark Approved, EMC Compliant |
| Waterproof Rating | IP67 |
| Housing | Slim Single Row, Black Finish |
| Warranty | Lifetime |
